Ducati Diavel 1260 Smart Turn Signal Integrator Kit

175 reviews   |

Custom LED

$149.99

In Stock! Orders received before Noon ET ship same business day. Add items to the shopping cart to view shipping rates and methods.

Share:
  • Complete Plug & Play Turn Signal Integrator Kit for the 2019-2022 Ducati Diavel 1260 & 1260S.
  • NEW 2nd Generation kit has a more compact design with additional programming features and functions.
  • Effectively controls the OEM brake lights to function as running light, brake light and turn signals.
  • Built-in user selectable 11 pattern brake modulator.
  • Slim-line compact and water-resistant construction 3.9" x  1.6"  x  0.6".
  • Comes with detailed installation instructions.
  • Plug & Play connectivity.
  • Full CANBus system compatibility.
  • US PATENT 8,588,997.
  • Made in the USA.
  • 2-year Warranty & Satisfaction Guarantee.
  • Ships same business day.

Overview

The Diavel 1260 & 1260S Smart Turn Signal Integrator Kit is a model-specific Smart Triple Play module and CanBus compatible wiring harness specific for installation on the Ducati Diavel. This complete Plug & Play kit converts the factory rear run/brake lights to operate as run, brake and turn signals in the most effective way possible.  The installation is fully reversible - no cutting or splicing at all.

2nd Generation Kit advanced features include: awesome startup sequence, built-in 11-pattern brake modulator which can also be disabled, adjustable running light brightness, Strobe Mode!, Demo Mode, and full-contrast blinker function (from full off to full bright).  This type of Brake Light Modulation has been a huge success with our Brake Alert feature found in our Blaster-X line of integrated tail lights.

Features

Features and Specifications:
  • Designed to be fully compatible with the Diavel 1260 specifically.
  • Allows existing factory brake lights to function as running light, brake light and turn signals.
  • Built-in 11 pattern brake modulator.
  • Works in conjunction with the factory turn signal lamps as well if desired.
  • Full-Contrast blink function allows blinker lamps to blink from OFF to FULL BRIGHT for maximum visibility.
  • Supports ignition-off hazard function.
  • Strobe Mode!
  • Slim-line compact and water-resistant construction 3.9" x  1.6"  x  0.6".
  • Comes with detailed instructions.
  • Plug & Play connectivity.
  • Full CANBus system compatibility.
  • US PATENT 8,588,997.
  • Made in the USA.
  • 2-Year manufacturers warranty.
Programmable Features:
  • Enable or Disable the Startup Sequence.
  • Set the Brake Alert Pattern.
  • Set the Running Light Brightness (within a preset range).
  • Engage Strobe Mode (Useful for Parades, Police Operations, and Bike Shows).
  • Enter Demo mode (Useful for Bike Shows and Dealer Displays).
  • Reset Factory Defaults.
User Selectable Brake Alert Patterns:
  • Pattern 1: Four Flashes then Solid.
  • Pattern 2: Four Flashes, Solid for 3 Seconds, Repeat.
  • Pattern 3: Seven Flashes then Solid.
  • Pattern 4: Seven Flashes, Solid for 3 Seconds, Repeat.
  • Pattern 5: Quad Strobe, Solid for 1 Second, Quad Strobe, Solid.
  • Pattern 6: Quad Strobe, Solid for 1 Second, Quad Strobe, Solid for 3 Seconds, Repeat.
  • Pattern 7: Strobe Mode Cycle for 3 Seconds, Solid.
  • Pattern 8: Strobe Mode Cycle, Solid for 3 Seconds, Repeat.
  • Pattern 9: 4 Quick Strobes, Solid (Factory Default).
  • Pattern 10: 10 Quick Strobes, Solid.
  • Pattern 11: Constant Quick Strobes (while braking).
  • Pattern 12: No Brake Alert (solid red).

Video

We have a large collection of all Custom LED product videos on the Custom LED YouTube Channel.

The videos in this playlist below are a collection of user-submitted and original videos related to the this product.  Note: Some videos may contain the xDiavel, and some the Diavel 1260.  The kit functions the same on both motorcycles.  Also, some videos may be of the Gen 1 kit and some of the Gen 2 kit.

Installation

The Ducati Diavel 1260 Smart Turn Signal Integrator Kit is installed on the motorcycle according to the detailed instructions below.



Gen 2 Diavel 1260 & 1260S Smart Turn Signal Integrator Kit - Installation Instructions

Click icon to download.
Adobe Acrobat Reader is required to view this file.
If you are having problems viewing the file, please download the free software here.
